Battery Holder 3AA

Williams REF #5881-09021-00





£5.00

Battery Holder 3AA WMS Plastic used on WPC CPU PCB



Not Available

Data East / Sega / Stern Battery Holder. 3 AA holder with top to tail battery arrangement and PCB and two pcb mounting pins.



£2.00

Universal Remote 3AA Battery Holder - To replace single rechargeable battery on Bally MPUs. With diode to prevent charging of non-rechargable cells.



£4.50

Universal Remote 3AA Battery Holder. NO DIODE. For remotely replacing all PCB mounted 3AA battery holders.



£3.00













27 Ohm 5 Watt Resistor for Early Williams Power Driver PCBs



£0.75

1.8K, 5 Watt Resistor , Cement - Used on WPC Dot Matrix Driver Power Supply

Specify WPC or WPC 95

£0.50

120R, 5 Watt Resistor , Cement - Used on WPC Dot Matrix Driver Power Supply

Specify WPC or WPC 95



£0.50

4.7K, 5 Watt Resistor , Cement - Used on WPC Dot Matrix Driver Power Supply

Specify WPC or WPC 95



£0.50

4.7K, 0.5 Watt Resistor - Used on WPC Dot Matrix Driver Power Supply at R91



£0.30

68R, 0.5 Watt Resistor - Used on WPC Dot Matrix Driver Power Supply



£0.30

270R, 3W Resistor - Used on Williams trough opto boards



£0.25

Crimp terminal .1" for housing below

£0.09

Housing .1" 21 Way. Can be cut for smaller lengths.

£0.96

Header Pins .1" 15 way

£1.65

IDC Connector 12–way. 0.156” Pitch

£1.00

IDC Connector 11–way. 0.156” Pitch

£1.00

IDC Connector 9–way. 0.156” Pitch

£0.75

IDC Connector 7–way. 0.156” Pitch

Each IDC connector includes 1 polarizing insert.

£0.75

IDC Molex Insertion Tool. 0.156”



£9.00

0.156" Connectors–CRIMP STYLE



Crimp terminal .156" for housing below.

£0.09

0.156” Crimp Terminal Housings with locking ramp. Available in 2,3,4,5,6, 7,8,9,10,11,12,13,14, and 15 Ways

£0.05 per Way  e.g. 11 Way = 55p

Polarising Insert for 0.156” Housing.

£0.15

Header pins 0.156" with friction lock - black. For GI and other connections

£0.15 per way to maximum 24 ways

J120 Kit—11 Way parts for replacing J120 or J121 Connector. Contains 1 header, 1 housing, 10 crimp terminals

£2.65

Rear Entry Female Housing 8 way. Used to connect early Williams processors to power driver boards. 5 required for each board.

£1.25

Ratchet Crimp Tool—The best economic tool I’ve found for crimping 0.1” and 0.156” crimp terminals.





£29.00





Data East / Williams Power Repair Kit

This 14 piece Connector Rebuild Kit will completely overhaul the troublesome Data East CN1 and Williams 3J2 male and female power supply connectors. Contains 11 female and 1 male terminal, 12 position (4x3) housing and corresponding pcb headers.

£5.00

Molex In-Line Connector Kit 9-Way (20pcs)

One Male and One Female housing each with 9 pins.



£4.00

Molex In-Line Connector Kit 3-Way (5pcs)

One Male and One Female housing each with 3 pins

£2.50

KBPC3502W 35A Wire leads Bridge Rectifier.

We also advise that you change the associated capacitor C5 at the same time.



£3.00

Capacitor 15,000uF 25V for general use on Williams power driver board and in association with the above bridge



£3.85

BR2 Kit - Bridge rectifier and capacitor, plus small amount of heat transfer compound



£7.00

10mH Inductor - Problems with Mist Multiball on Dracula. Check the Inductor on the control PCB—bet its hanging off!!



£1.25

Home Page

Battery Holders

Balls

Ball Shooter Parts

Bolts

Brackets

Cabinet Parts

Capacitors

Circuit Boards

Cleaners

Coils

Connectors

Coloured Lamps

Decal

Displays

Drop Target Parts

EOS Switches

Fender Washers

Flipper Parts

Fuses

Game Specific Parts

Integrated Circuits

Lamps

Lamp Holders

Lamp Covers

Metal Posts

Mechanical Assemblies

Microswitches

Motors

Mylar Protectors

Nuts

Opto Switches

Pinball 2000

Plastic Posts

Pop Bumper Parts

Resistors

Ring Kits

Rubbers

Springs

Stand Up Targets

Tools

Transistors

Washers



Order Code



2 x 34-pin 3.75" WPC/95 MPU– POWER DRIVER

p/n. 5795-12653-03

Ribbon01

£6.50

2 x 26-pin 14" WPC CPU - DMD

p/n. 5795-10868-14

Ribbon02

£11.00

4 x 34-pin 23.5" WPC CPU/FLIPTRONIC/SOUND/DMD

p/n. 5795-13018-01

Ribbon03

£12.00

2 x 14-pin 32"

p/n. 5795-12653-32

Ribbon04

£11.00

2 x 34-pin 20"

p/n. 5795-12653-20

Ribbon05

£11.00

2 x 26-pin 32"

p/n. 5795-10868-32

Ribbon06

£11.00

Gottlieb System 80 Wiring harness

Ribbon07

£29.95

2 x 14-pin 30" Display Connector

p/n. 5795-12838-30

Ribbon08

£9.00

2 x 26-pin 15” WPC CPU—DMD

5795-10938-15

Ribbon09

£11.00

2 x 26-pin 36"

p/n. 5795-10868-36

Ribbon10

£14.00

3 x 26-pin 20"

p/n.

Ribbon11

£11.00
